What is eye tracking?

July 13, 2018 by Sam Hutton

What is eye tracking?

What is eye tracking? Put simply, eye tracking is the process of measuring eye movements. A typical goal for eye tracking research is to establish where people look (i.e., their “point of regard” or “gaze”). To this end, scientists usually use a video-based eye tracker, such as the EyeLink 1000 Plus. Video-based eye trackers, in addition to monitoring gaze, can reveal other useful measures including pupil size and blink rate.



Why are scientists interested in eye tracking?

One of the most common rationales for eye tracking is known as the “Eye-Mind Assumption”. This is essentially the idea that we focus our limited processing resources on the information we are looking at. By monitoring our eye movements, researchers attempt to infer what is happening in our brain.



Vision

To better understand the Eye-Mind Assumption, it is necessary to briefly consider eye physiology. Only a relatively tiny part of our retina, the fovea, contains a sufficient density of cones (color sensitive cells) to resolve the visual world in significant detail. The fovea itself covers an area of only 1-2 degrees of visual angle. The rest of the scene is mainly processed by rod cells. Rods are sensitive to light and dark changes, and allow us to detect large shapes and motion – but not fine detail. The figures below illustrate cone and rod cells density and distribution.



Rods and cones density
Figure 1: Cone and rod density visualized on an eye diagram (left) and a more typical graph (right).


Given that our perception of the world seems relatively detailed, it may be a surprise that only an area the size of a coin held at arm’s length is actually being “seen” in detail. We construct a perception of the outside world from a series of snapshots by moving our eyes (re-orienting the fovea) approximately three times every second. These rapid reorienting eye movements are known as saccades. In between saccades, the eye “fixates” and is relatively still. We process only the visual information acquired during fixations.



Eye Tracking and the Eye-Mind Assumption

So as a consequence of a small fovea, our brain makes a very important decision about three times every second: Where, and when, should the eyes move. We make many decisions each day – including what to eat, which coffee to choose or whether to move the queen in a game of chess. These decisions are influenced by many factors, such as our previous experience of similar situations and our current emotional state.


Eye tracking options

Importantly, these same factors can also influence our decisions about where to look next. So our intentions, goals, expectations, memories, beliefs, and even our personality types can all influence where we choose to look. Psychologists, neuroscientists, and many other researchers use eye tracking to explore these processes. For example, a researcher can study the differences in eye movements between expert and novice chess players to understand the relationship between chess expertise and memory for chess positions.


Chess and eye tracking

How can eye tracking help my research?

By analyzing eye-movement data, for example where people fixate and how long they fixate for, researchers can gain important insights into a number of cognitive operations involved in a wide range of behavior. For example, with eye tracking data, applied researchers can study how shoppers make purchasing decisions and how radiologists interpret x-ray images. Language researchers can use eye tracking to examine how people read and comprehend spoken language. In addition, by studying infants, children and adults, developmental researchers can learn how these processes develop (and deteriorate). By studying eye movements in patients with disorders such as Alzheimers Disease or Schizophrenia, clinical researchers can gain insights into the disease processes themselves. Researchers can gain even more insights by integrating eye tracking with other neuroimaging technology such as EEG, fNIRS, and fMRI.

So next time you are struggling to decide which coffee to order, take comfort that your brain is already making several critical decisions, every single second.



Related Posts

Eye Tracking Terminology
Eye Tracking Terminology – Eye Movements
when do babies track an object
When do babies track objects?
Visual Angle Calculation
Visual Angle



Contact

If you would like us to feature your EyeLink research, have ideas for posts, or have any questions about our hardware and software, please contact us. We are always happy to help. You can call us (+1-613-271-8686) or click the button below to email:

Get in Touch

Filed Under: Background Tagged With: Eye Tracking

About Sam Hutton

Sam Hutton studied Experimental Psychology at the University of Sussex, and liked it so much he stayed there to do a PhD. His first encounter with an eye tracker was during his post-doctoral fellowship at Imperial College, London. He was based in the Neuro-opthalmology unit at Charing Cross Hospital for 6 years, and whilst there learned to use an ancient infrared eye tracking system to measure basic oculomotor function (prosaccades / antisaccades / smooth pursuit etc) in patients with neuropsychiatric and neurological disorders. He was hooked, and has been actively involved in eye tracking research in one way or another ever since. When not writing blogs (e.g. most of the time...) he works with the rest of the SR Research Support Team on a range of projects, taking a particular interest in issues involving eye tracking in clinical settings (for example eye tracking nystagmus / neurological disorders) and pupillometry. He can also be found teaching eye tracking workshops on a range of topics, and generally trying to make sure that people don't make the same mistakes he did. He loves to eye track animals, and has so far managed to record gaze from mice, cats, dogs and a duck...
